Stainless Steel Trim Front Lit Led Letters Outdoor
Our LED channel letters are engineered for maximum performance and longevity.
Factory quoteMOQ 1 piece
Details
Outdoor signage
LED Outdoor Letters
Outdoor LED letters fail for one reason more than any other: water getting in where the cable enters. The LED modules themselves are reliable. This page covers the specification that keeps an outdoor sign running through ten winters.
- IP65 to IP68 rated LED modules, matched to the exposure
- Sealed cable entries and branded drivers
- Operating range −20 °C to +50 °C for the standard build
- 50,000+ hours LED lifespan, 3-year warranty on LED components
+86 152 5645 2807 Opens WhatsApp chat
The specification that matters outdoors
| Part | Specification | Why |
|---|---|---|
| LED modules | IP65 to IP68, branded | Water and dust ingress is the main failure mode |
| Driver | Mean Well or Huaxin, correctly loaded | The most common warranty claim |
| Cable entry | Sized gland, sealed | Where most intermittent faults begin |
| Wiring | DC12V/24V with protection | Safe low-voltage system with fault protection |
| Finish | Powder coat or baked enamel | Survives UV, rain and temperature cycling |
| Testing | 24-hour lighting test | Catches faults before shipping, not after installation |
Matching the build to the exposure
- Under a canopy or recessed: IP65 and standard sealing are usually sufficient
- Fully exposed façade: IP67 or IP68 modules, sealed entries and stainless fixings
- Coastal or high-salinity sites: grade 316 stainless returns to resist pitting
- High-wind or high-vibration locations: heavier fixings and a sub-frame where needed
Tell us where the sign is going — covered, exposed, coastal — and we will specify the rating, the materials and the fixings for that environment rather than quoting a generic outdoor build.
Keeping it running
- Clean the faces twice a year; grime reduces light output and ages the appearance
- Check seals and cable entries before winter
- Photograph the sign lit at night each year to spot colour drift early
- Keep spare modules with matching colour temperature
Summary
Outdoor LED letters are bought on three numbers you never see on the front: IP rating, driver brand and how well the cable entry is sealed. Specify those, and the sign outlives the shopfront it is attached to.
Specification
What you can specify
These are the options that come with a standard build. Sizes, finishes and lighting can all be adjusted to the site — tell us the conditions and we will recommend a configuration.
| LED Power Supply | AC, DC, Plug, Transformer |
|---|---|
| Warranty | 3 year |
| Applications | Building, Bar, Companies, Event&Party, Mall, Office, Shops, Hotels, etc. |
| Optional LED Brands | Rishang, Blueview, LEDIT YAKI |
| Optional transformer brands | Huaxin, Mean Well |
| Color Mode | Multi Colors, One Color, rgbic color |
| Control | Controller, Remote Control, App Control, Manual Control |
| Certification | CE, RoHS, EMC, UL |
| Operating Temperature | -20℃ to +50℃ |
Popular for this order
Every sign is made to order in our own factory in Lu'an, Anhui — MOQ is one piece and free design support is included.
Channel Letters
Backlit Sign with Durable Baked Enamel Finish
Crafted with a stainless steel body and a premium baked enamel finish, our halo-lit letters combine rich,…
Factory quoteMOQ 1 piece
Details
Perforated Sign
Starry-Sky LED Channel Letters
Crafted entirely from stainless steel and covered with irregular perforations, our starry-sky LED channel…
Factory quoteMOQ 1 piece
Details
Questions buyers ask
What IP rating do outdoor LED letters need?
IP65 for sheltered positions, IP67 or IP68 for fully exposed facades and coastal sites. The rating is matched to the exposure rather than applied as a blanket minimum.
How long do outdoor LED letters last?
Modules are rated at 50,000+ hours and operate from −20 °C to +50 °C in the standard build, with a 3-year warranty on LED components and 5 years on the structural aluminium housing.
What is your minimum order quantity?
Our MOQ is one piece. We welcome custom orders of any size, from a single sign for a small business to complete signage solutions for commercial projects. As a direct signage manufacturer we provide professional design support, custom production, quality inspection and global delivery for every order.
Can you match our brand colours and logo?
Yes. Send us the artwork and we will reproduce it in the construction that suits your project. Custom colours can be spray painted to your PANTONE or RAL reference, and metal parts are available in brushed or mirror stainless steel with electroplated finishes including titanium gold, champagne gold, rose gold, black steel, antique bronze and antique brass.
